Specifications |
Item No. | Components | Descriptions |
Core | Android board | RK3288,Quad core CPU,8GB memory,HDMI VGA input USB port |
Android board | RK3188,Dual core CPU,4GB memory,HDMI VGA input USB port |
Advertising license | Advertising software with license |
Windows board | i3 CPU,4GB memory,500GB HDD,HDMI VGA ouput,USB,WiFi,RJ45 |
Windows board | i5 CPU,16GB memory,500GB HDD,HDMI VGA ouput,USB,WiFi,RJ45 |
Windows board | i7 CPU,16GB memory,500GB HDD,HDMI VGA ouput,USB,WiFi,RJ45 |
Windows license | Official Windows license |
AR glass | Quality high transmittance rate AR glass |
Modules | Nano Touch | 10dots Nano touch(standard) |
Heating module | Air conditionner cooling no need |
WiFi hotspot | WiFi hotspot module |
Normal built in Camera | 2 mega pixel built in camera |
Panel specification,input output port,mechanical properties |
Panel | Panel type | LG TFT LCD |
Physical Resolution | 1920*1080 |
Color depth | 10bit(D), 1.07Billon colors |
Viewing Angle | H178º/ V178º |
Luminance(nits) | 2000cd/m2 |
Contrast | Typical:1100,MIN:800 |
Backlit type | LED |
Response time | 6ms |
Life(hrs) | more than 60000 |
Core Board | BOARD | Optional from above |
Consumption | Power Supply | AC100~240V 50/60Hz |
Standby/Max.Consumption | ≤1300W |
Speaker | 2 x10W |
Working function &Environment | Control Method | Depends on above board choosen |
Color System Support | PAL/NTSC/SECAM |
OSD Language | English/Multiple Language |
Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolutions |
Video format support | MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI |
Image format support | JPEG/BMP/TIFF/PNG/GIF |
Audio format support | Wave/MP3/WMA/AAC |
Splicing Display | Support |
Working Temperature | -40℃-50℃ |
Working Humidity | -40%-55% |
Storage Temperature | 0℃-50℃ |
Storage Humidity | 5%-95% |
Cooling | Fan cooling |
Appearance & packing | Application Condition | Pure outdoor all weatherproof |
Material | Cold-roll steel SPCC |
Frame Color | Black/White/Silver/Customization |
Mount/Installation type | Standing,iPhone seamless design |
Packing way | Safe packing with bubble foam, in wooden case |
Packing Weight | 120KG /unit for 43 inch |
Quality Standard | ISO9001,CE,RoHS,FCC,CC |
