21" Floor Standing Portable Selfservice Payment Kiosk For Shopping
Mall
Product details:
| Resolution | 1920*1080 |
| Panel | BOE original panel, A level |
| Display area | 934*525mm |
| Brightness | 350cd/m2 |
| Number of Color | 16.7M |
| Response time | 8 (ms) approximately |
| Contrast | 1200:1 |
| View angle | 178°/178°(H/V) |
| Life Time | > 50000 (hours) |
| Power Supply | AC 110V~240V,50/60HZ |
| Power Consumption | 80W |
| Photo Formats | JPEG ,BMP ,GIF ,PNG |
| Audio Formats | MP3,WAV,WMA |
| Video Format | MP4,AVI,DIVX,XVID,VOB,DAT,MPG,MPEG,RM,RMVB,MKV,MOV,HDMOV,M4V |
| Shell Material | Aluminum+Metal |
| Bare dimension | TBC |
| Wooden box dimension | 3pc screen/box: 1.26*0.71*0.81M, 3pc stand/crate: 1.72*0.84*0.71M,
total weight: 230KG |
| Color | White / black |
| QR code scanner | Inbuilt, has NFC card reader function |
| Touch Type | 10 points PCAP touch screen |
| Printer | Thermal printer inbuilt |
| Pos machine | From client |
| Normal Working Temperature | 0°——50° |
| Normal Storage Temperature | -20°——60° |
| CPU | RK3288 Quadcore Cortex-A17 1.8GHz |
| Network connection | LAN, WIFI |
| RAM | DDR3 2G |
| Memory | 8G |
| The operating system | Android 7.1, support Google play |
| Interface | HD.MI out*1, USB*1, USB OTG*1, Lan*1, SD card*1 |
| CPU | I3/I4/I7 |
| Network connection | LAN, WIFI |
| Memory | DDR3 4G |
| SSD | 128G |
| The operating system | Trial Win10 |
| Interface | HD.MI out*1,USB *4 ,LAN *1, VGA*1 |
Application
Company profile
Guangzhou Jingdinuo Electronic Technology Co., Ltd. which is the
first professional manufacturer of commercial display
equipment. We have more than 20 years production experience and
over 10 years export trade.
All of our product have strict inspection and passed the CE, CCC,
RoHS, FC and IEC certifications to insure quality. We
owe 2000 square meters large factory. We have won the big support
from the customers through the efforts of more than
100 colleagues.We have professional technical personnel, rich
operational experience and excellent technical strength etc.
Professional designers team make sure to meet customers’
requirements. Until now our products and services have r
ecognized by customers.
Quality control
All of our product have strict inspection and passed the CE, CCC,
RoHS, FC and IEC
certifications to insure quality. We owe 2000 square meters large
factory. We have won
the big support from the customers through the efforts of more than
100 colleagues.
Exhibition
Our main products:
Stand floor digital signage/ Wall mount digital signage/ Outdoor
digital signature/
Elevator digital signage/ Hanging double side digital signage/ LCD
video wall/
Transparent showcase etc.
Welcome to cooperate on mutual benefits together. Many thanks!
