K Type Horizontal Multitouch All In One Smart Interactive
Whiteboard
K type horizontal multitouch all in one Smart Whiteboard Infrared
Touch display screen
Product Features:
1, From 32 inches to 100 inches, suitable for different space needs
2, Different chips can be selected, i3, i5, and I7 can be selected
according to the performance requirements
3, Dual system control of conference tablet all-in-one: The smart
conference tablet all-in-one has built-in Windows and Android dual
systems, which can be switched freely with just one key, and it can
easily cope with various meeting environments.
4, The conference tablet all-in-one has precise touch control and
free handwriting: a free and smooth writing experience, supports
gesture erasing, zooming in and out, and dragging.
5, Multi-person interaction on the same screen adopts wireless
transmission technology, and users do not need to project through a
data line to achieve wireless projection. Compatible with all
devices, whether it is a smart phone, a tablet computer, or a
traditional notebook computer, the content can be transferred to
the conference all-in-one machine; and the two-way operation
between the PC and the conference all-in-one can be realized.
Supports multi-person interaction on the same screen, such as
mobile phones and tablets, multiple mobile devices can be connected
to the same network to achieve two-way interaction on the same
screen.
6. Built-in wifi: without laying an expensive video conferencing
network, with built-in wifi just ordinary network can be realized
dual-system operation windows& Android depth of integration, data
sharing HD, smooth, stable video conference.
| Dual Systems Parameter : |
| Type | interactive whiteboard | CPU | Intel i3/i5/i7 |
| OPS | win7/win10 | Android OS | Android 5.1 |
| Size | 100'' | Size of product | 1514.8*102.6*934.7mm |
| Size of display | 1652*930mm | Size of package | 1942 x 1280 x 300 mm |
| N.W.(KGS) | 85KG | G.W.(KGS) | 85KG |
| Resolution | 3840*2160(4K) | Display colors | 8 bit/16.7 Billion |
| Capacity | ≤300W | Respond time | 8ms |
| Brightness | 350(cd/m2) | Lifetime | ≥60000h |
| Type of display | LED | Resolution ratio | 32768(E)*32768(D) |
| Touchpoint | 10 points | Max. viewing angle | 178° |
| Contrast ratio | 1200:1TYP | Working voltage | 50-60HZ 100-240V |
| Standby power | 3W | Working temperature | 0~60℃ |
| Panel | Samsung, LG or BOE | Touch accuracy | ±2mm |
| Backlight | DLED | Power of speaker | 8Ω10W*2 |
| Recognizable object | ≥Φ5mm opaque object | Glass type | tempering 4mm AG |
| Front ports | Infrared touch port*1;HDMI*1,PC-3.0*1;TV-USB2.0*1;Audio in*1;VGA*1; |
| Back android ports | RS232*1;MIC*1;Touch port *1;TF*1; USB2.0*2; HDMI*1;SPDIF*1;VGA out
*1;VGA in *1; VGA Audio in*1; YPBPR*1;AV1*1;AV2*1;AV
out*1;earphone*1;RF*1;WIFI*1; |
| Back PC ports | HDMI*1;USB3.0*2;USB2.0*2;VGA*1;network
output*1;HDMI*1;USB3.0*2;USB2.0*2;VGA*1;network output*1;Microphone
in*1 |
